Product Details:
| Place of Origin: | Jewelry Tester Supplier |
| Brand Name: | VRAY |
| Certification: | ISO CE GOST |
| Model Number: | VR-T7 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | 20000$-22000$ |
| Packaging Details: | Strong Case |
| Delivery Time: | 7 days |
| Payment Terms: | TT |
| Supply Ability: | 500 units per month |
A High Precision Diamond Gold Tester is an advanced X-ray Fluorescence (XRF) machine designed for exceptionally accurate and non-destructive elemental analysis of gold, silver, other precious metals, and supporting diamond assessment by precisely analyzing their settings. Characterized by its High sensitivity SDD detector and remarkable 0.01% accuracy for 9999 gold, these desktop testers are built for reliable gold testing in professional environments, offering detailed compositional analysis and features like a manual sample XY platform for precise targeting of small areas, making them ideal for high-value items and demanding laboratory applications.
Model | VR-T7 |
Type | High Precision Diamond Gold Tester |
Price | 20000$-22000$ |
Machine size | 330 x 580 x 360mm |
Chamber size | 320 x 480 x 130mm |
N/G Weight | 40Kg/60KG |
Test time | 30s |
Test range | Solid/liquid/ powder |
Detector type | High sensitivity SDD detector |
Test accuracy | 0.01% for 9999 gold |
X-ray tube | 50W (50 kV, 1mA) micro-focused beryllium window |
Collimator | ϕ1.5mm |
Manual sample XY platform | Moving range：50x50 mm |
Safety protection | Have radiation report.Equipped with a dedicated T-shaped radiator to dissipate the heat；no need to wait for cooling of |
Camera | High resolution CMOS color camera, 5 million pixels |
Magnification | 40x-160x |
Rated power | 100W |
Temperature | 10℃～35℃ |
The VRAY VR-T7 High Precision Diamond Gold Tester is a cutting-edge desktop gold tester meticulously engineered for reliable gold testing with unparalleled accuracy, making it an essential tool for environments handling high-value precious metals and jewelry.
This High Precision Diamond Gold Tester features a High sensitivity SDD detector and a powerful 50W micro-focused beryllium window X-ray tube with a ϕ1.5mm collimator. It achieves an outstanding 0.01% accuracy for 9999 gold and provides comprehensive analysis in a rapid 30 seconds for solid, liquid, or powder samples. Its ability for precise targeting is enhanced by a Manual sample XY platform with a 50x50 mm moving range, a High resolution CMOS color camera with 5 million pixels, and impressive 40x-160x magnification. Despite its powerful capabilities, it maintains a manageable desktop size (330 x 580 x 360mm) and weight (40Kg N/G Weight). Designed for continuous, reliable operation, it includes a dedicated T-shaped radiator for efficient heat dissipation, ensuring no cooling waits and having a radiation report for safety assurance. Operating reliably within 10℃～35℃, the VRAY VR-T7, priced between $20,000-$22,000, is the definitive High Precision Diamond Gold Tester for the most reliable gold testing needs.
The VRAY VR-T7 High Precision Diamond Gold Tester is packed with advanced features designed for ultimate precision and reliable gold testing:
Exceptional Accuracy: Achieves an industry-leading 0.01% accuracy for 9999 gold, setting a high standard for reliable gold testing and purity verification.
High Sensitivity SDD Detector: Utilizes a state-of-the-art High sensitivity SDD detector, providing superior energy resolution and low detection limits crucial for precise elemental analysis.
Rapid Test Time: Delivers precise analytical results in a swift 30 seconds, significantly accelerating lab throughput and operational efficiency.
Versatile Sample Compatibility: Capable of analyzing solid, liquid, and powder samples, accommodating a wide range of materials from raw precious metals to finished jewelry.
Advanced X-ray Tube: Equipped with a 50W (50 kV, 1mA) micro-focused beryllium window X-ray tube and a ϕ1.5mm collimator, optimizing excitation for precise results across various elements.
Precision Sample Positioning: Features a Manual sample XY platform with a 50x50 mm moving range, allowing for exact targeting of specific areas on small or intricate jewelry pieces.
High-Resolution Imaging: Includes a High resolution CMOS color camera with 5 million pixels and 40x-160x magnification, enabling detailed visual inspection and precise placement of the sample.
Robust Safety Protection: Comes with a radiation report and is equipped with a dedicated T-shaped radiator to dissipate heat, ensuring continuous, safe operation without needing to wait for cooling.
Desktop Form Factor: A stable and robust desktop unit (40Kg N/G Weight) with practical dimensions (330 x 580 x 360mm), designed for consistent performance in a fixed location.
The High Precision Diamond Gold Tester (VRAY VR-T7) is an indispensable tool for applications where reliable gold testing and the highest level of precision are critical:
Professional Gemological & Assay Laboratories: The primary application, used for certifying the purity of gold, platinum, and silver, especially in settings with diamonds, requiring detailed elemental analysis and trace element detection. This ensures reliable gold testing for valuation and authentication.
Luxury Jewelry Manufacturers & Brands: For rigorous quality control of incoming raw materials, finished high-end jewelry (including diamond settings), and custom pieces, guaranteeing precise alloy compositions and accurate karat values.
National Mints and Central Banks: For verifying the exact composition and purity of gold and silver bullion, investment coins, and other precious metal assets, ensuring compliance with international standards and preventing counterfeiting.
High-End Pawn Shops and Auction Houses: For accurately appraising very high-value jewelry with diamonds, antiques, and rare coins where minuscule variations in purity can significantly impact value.
Research & Development in Metallurgy: For studying new precious metal alloys, analyzing material properties, and conducting failure analysis where extremely precise elemental composition data is required.
Anti-Counterfeiting Operations: Provides definitive, non-destructive verification of authenticity for gold and diamond-set jewelry suspected of being fake or having misrepresented purity.
The VRAY VR-T7 High Precision Diamond Gold Tester sets a benchmark for reliable gold testing through its exceptional precision and accuracy:
Ultra-High Accuracy: Achieves an industry-leading 0.01% accuracy for 9999 gold. This means it can distinguish between very subtle differences in purity, which is crucial for certifying investment-grade gold or detecting minute impurities that could affect material properties or value.
High Sensitivity SDD Detector: The core of its precision lies in the High sensitivity SDD detector. This Silicon Drift Detector provides superior spectral resolution, allowing the machine to clearly differentiate between closely spaced elemental peaks. This minimizes peak overlap issues, leading to more accurate quantification of each element, including trace amounts.
Micro-Focused X-ray Tube with Beryllium Window: The 50W (50 kV, 1mA) micro-focused beryllium window X-ray tube ensures a stable and intense X-ray beam, effectively exciting elements in the sample. The beryllium window allows for efficient detection of lighter elements, contributing to a more complete and accurate elemental analysis.
Precision Collimator (1.5mm): The small collimator size ensures that only a precise spot on the sample is analyzed, preventing interference from surrounding areas, especially important for small or intricate jewelry pieces.
Manual Sample XY Platform and High-Resolution Camera (40x-160x magnification): These features allow the user to pinpoint the exact area of interest, ensuring that the analysis is performed on the desired material (e.g., the gold setting, not the diamond or another gemstone). This precise targeting is vital for achieving and maintaining high accuracy.
Comprehensive Data Processing: Combined with rapid 30-second test times, the system processes data quickly and accurately, providing reliable results consistently.
The High Precision Diamond Gold Tester (VRAY VR-T7) is essential for professionals and organizations that demand the utmost accuracy and reliability in precious metal analysis, particularly for reliable gold testing of high-value items:
Certified Assay Laboratories: Organizations providing official certification of precious metal purity for trade, legal, or investment purposes.
High-End Jewelry Houses and Manufacturers: Businesses creating or selling luxury jewelry, especially those incorporating diamonds, where material quality and authenticity are paramount to their brand reputation.
Gold and Silver Refineries: For final quality control of ultra-pure refined metals, ensuring they meet specific purity standards (e.g., 99.99% or 99.999%).
Large-Scale Precious Metal Dealers and Brokers: Companies involved in buying and selling significant quantities of gold, silver, and platinum.
Government Institutions (Mints, Central Banks, Customs): For verifying the authenticity and purity of national reserves, coinage, or confiscated precious metals.
Specialized Gemstone and Diamond Dealers: Who need to verify the metal composition of the settings of valuable diamonds and other gemstones accurately.
Research & Development Facilities: Academic or industrial labs conducting advanced materials science research on precious metals and alloys.
VRAY is committed to providing comprehensive technology support for its High Precision Diamond Gold Tester (VR-T7), ensuring reliable gold testing and optimal performance for demanding professional applications:
Expert Technical Assistance: Direct access to highly trained and experienced technical specialists for operational queries, advanced troubleshooting for complex analytical challenges, and expert advice on specific applications, including intricate diamond jewelry analysis.
Software and Firmware Updates: Continuous provision of software enhancements and firmware updates. These updates are vital for improving analytical algorithms, expanding element libraries, refining user interface features, and ensuring compatibility with evolving industry standards.
Precision Calibration Services: Dedicated support and services for maintaining the machine's exceptional 0.01% accuracy. This includes guidance on routine calibration checks using certified reference materials and specialized recalibration services performed by VRAY experts if needed.
On-Site Service and Repair: For complex issues or scheduled preventive maintenance, VRAY can deploy factory-trained engineers to your location to minimize downtime and ensure the machine operates at its peak performance for reliable gold testing.
Training and Resources: Offers comprehensive training programs (potentially on-site or virtual) for lab personnel on operating the VR-T7, interpreting its high-precision data, and leveraging all its features, including the manual XY platform and high-resolution camera. Detailed user manuals and application notes are also provided.
Application Support: Assistance with optimizing testing parameters for specific gold alloys, matrices (solid, liquid, powder), or challenging analytical requirements common in high-precision precious metal analysis.
The VRAY VR-T7 is a High Precision Diamond Gold Tester due to its cutting-edge High sensitivity SDD detector and an outstanding 0.01% accuracy for 9999 gold. This unparalleled precision ensures highly reliable gold testing, crucial for certifying purity in high-value gold items and accurately analyzing precious metal settings for diamonds.
This High Precision Diamond Gold Tester delivers rapid and precise analytical results in just 30 seconds. This speed is vital for reliable gold testing in busy professional environments, allowing for high-volume analysis without compromising accuracy.
You can expect industry-leading precision with this High Precision Diamond Gold Tester, offering 0.01% accuracy for 9999 gold. This exceptional accuracy ensures the most reliable gold testing, capable of distinguishing between minute purity differences, which is essential for investment-grade gold and valuable jewelry.
This High Precision Diamond Gold Tester ensures accurate analysis of small or intricate jewelry pieces through its Manual sample XY platform (with a 50x50 mm moving range), a High resolution CMOS color camera, and impressive 40x-160x magnification. These features allow for precise targeting of specific areas, guaranteeing reliable gold testing on complex designs.
This High Precision Diamond Gold Tester is highly versatile and capable of performing non-destructive analysis on solid, liquid, and powder samples. This makes it ideal for reliable gold testing of various forms, including gold and silver jewelry, raw materials, ingots, and even refining solutions.
Yes, this High Precision Diamond Gold Tester is designed with safety in mind. It has a radiation report confirming its safety and is equipped with a dedicated T-shaped radiator for efficient heat dissipation. This ensures reliable gold testing and continuous, safe operation without the need to wait for cooling.
