Product Details:
| Place of Origin: | Gold Tester Gun Manufacturer |
| Brand Name: | VRAY |
| Certification: | ISO CE GOST |
| Model Number: | VR-H5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | 15000$-18000$ |
| Packaging Details: | Strong Case |
| Delivery Time: | 7 days |
| Payment Terms: | TT |
| Supply Ability: | 500 units per month |
A Professional-Grade Gold Tester Gun is a handheld, high-performance X-ray Fluorescence (XRF) analyzer specifically engineered for rapid, non-destructive, and highly accurate analysis of gold and other precious metals.
Model | VR-H5 |
Type | Professional-Grade Gold Tester |
Price | 15000$-18000$ |
Machine size | 254 x 79 x 280mm |
Chamber size | 500 x 400 x 200mm |
N/G Weight | 1.6Kg（with battery）/ 7.1KG |
Test time | 30s |
Test range | Solid/liquid/ powder |
Detector type | Customized Si-Pin detector from USA |
Test accuracy | 0.03% for 9999 gold |
Excitation source | Up to 50KV/200μA， tube pressure and tube flow can be adjusted freely, Target Ag (standard), Au(optional), W(optional), Rh(optional) |
Sreen | 4.3" industrial resistive touch screen |
Memory | 32GB |
Heat dissipation | Equipped with a dedicated T-shaped radiator to dissipate the heat； no need to wait for cooling of |
Power supply system | Intelligent battery with MSBUS bus, complies with air dangerous goods transport regulations, one battery can work for about 8 hours |
Data transmission | USB or bluetooth |
Rated power | 100W |
Temperature | -20℃～50℃ |
The VRAY VR-H5 Professional-Grade Gold Tester Gun is a cutting-edge handheld device designed for superior accuracy and comfort during prolonged use, featuring a meticulously crafted ergonomic grip.
This Professional-Grade Gold Tester Gun is equipped with a Customized Si-Pin detector from USA and a powerful excitation source (up to 50KV/200μA, with adjustable tube pressure and flow, and optional targets: Ag standard, Au, W, Rh). It delivers exceptional 0.03% accuracy for 9999 gold and rapid 30-second test times for solid, liquid, or powder samples. Its compact size (254 x 79 x 280mm) and lightweight design (1.6Kg with battery) are complemented by the ergonomic grip for comfortable handling. The 4.3" industrial resistive touch screen and built-in 5 million high-definition camera offer intuitive operation and precise sample targeting. With an intelligent battery system providing approximately 8 hours of continuous work and robust operation across a wide temperature range of -20℃ to 50℃, the VR-H5 is the definitive Professional-Grade Gold Tester Gun for high-precision, mobile elemental analysis.
The VRAY VR-H5 Professional-Grade Gold Tester Gun boasts features that combine high performance with user comfort:
Ergonomic Grip: Designed for comfortable and stable handling during prolonged use, reducing operator fatigue.
Superior Accuracy: Achieves 0.03% accuracy for 9999 gold with a Customized Si-Pin detector from USA.
High-Performance X-ray Tube: Excitation source up to 50KV/200μA with adjustable pressure and flow, and optional targets (Ag standard, Au, W, Rh) for optimized elemental analysis.
Rapid Test Time: Delivers precise results in a swift 30 seconds.
Ultra-Lightweight: Weighs only 1.6Kg (with battery), making it highly portable and easy to carry.
Long Battery Life: Provides approximately 8 hours of continuous work on a single charge.
Versatile Sample Compatibility: Capable of analyzing solid, liquid, and powder samples.
Intuitive Interface: Features a 4.3" industrial resistive touch screen and a built-in 5 million high-definition camera for precise targeting.
Robust Environmental Tolerance: Operates reliably in temperatures from -20℃ to 50℃.
Efficient Heat Dissipation: Equipped with a dedicated T-shaped radiator for continuous, stable operation.
The Professional-Grade Gold Tester Gun (VRAY VR-H5) offers compelling advantages for users demanding top-tier performance and usability:
Exceptional User Comfort: The ergonomic grip significantly reduces hand strain, allowing professionals to perform more tests throughout the day without discomfort, increasing productivity.
Unmatched Portability: At just 1.6Kg, it's incredibly light, enabling easy transport and operation in diverse field conditions, from crowded stores to remote mining sites.
High-Precision Results: Offers 0.03% accuracy for 9999 gold, providing critical confidence in valuing high-purity gold and preventing financial losses from misidentification.
Rapid On-Site Analysis: Delivers results in just 30 seconds, speeding up transactions, improving customer service, and streamlining workflows.
Versatile Application: Capable of analyzing a wide range of elements and sample types (solid, liquid, powder), extending its utility beyond just gold to other metals and materials.
Durable and Reliable: Built to withstand demanding environments (operating from -20℃ to 50℃) and designed for continuous use, ensuring long-term reliability and minimal downtime.
The Professional-Grade Gold Tester Gun is an indispensable tool across various industries requiring precise, mobile, and non-destructive metal analysis:
Jewelry Retailers & Manufacturers: Rapidly verifies the karat value and elemental composition of gold, silver, platinum, and palladium jewelry, ensuring quality control and preventing sales of misrepresented items.
Pawnshops & Gold Buyers: Provides immediate and accurate appraisal of precious metal items, including distinguishing real gold from plated or fake items, for fair and confident transactions.
Precious Metal Refineries: Conducts quick screening of incoming scrap, dental alloys, and other materials to identify precious metals and assess impurities.
Scrap Metal Recycling: Efficiently identifies and sorts various metal alloys (e.g., stainless steel grades, aluminum series, copper alloys) directly in the scrap yard, maximizing material value.
Mining & Exploration: Field-based elemental analysis of geological samples (rock, soil, ore) for rapid mineral identification and grade control at exploration sites.
Quality Control (Positive Material Identification - PMI): Verifying the elemental composition of metal components in manufacturing, construction, and petrochemical industries to ensure material compliance and safety in the field.
VRAY typically provides comprehensive technology support for its Professional-Grade Gold Tester Gun (VR-H5) to ensure optimal long-term performance and user satisfaction:
User Manuals and Documentation: Detailed guides for setup, operation, calibration, and troubleshooting, specifically tailored for handheld field use.
Technical Support Hotline/Email: Direct access to technical experts for assistance with operational queries, advanced troubleshooting, and application-specific guidance.
Software Updates: Regular firmware and software updates to enhance analytical capabilities, improve the user interface, and optimize performance.
Calibration Services: Support for re-calibration using certified reference materials, either remotely or through authorized service centers, to maintain the analyzer's high accuracy.
Repair and Maintenance Services: Access to professional repair and maintenance services for hardware components, minimizing downtime and ensuring the analyzer remains in peak operating condition, even after demanding field use.
Online Resources: Potential availability of FAQs, video tutorials, and knowledge bases online for convenient self-help and learning.
The VRAY VR-H5 is a Professional-Grade Gold Tester Gun due to its exceptional 0.03% accuracy for 9999 gold, robust construction, powerful High-performance X-ray Tube, and user-centric design with an ergonomic grip. It's built for demanding professional use, providing rapid (30s test time) and reliable results in various field and commercial settings.
The ergonomic grip of this Professional-Grade Gold Tester Gun is crucial for user comfort and efficiency. It significantly reduces hand fatigue during extended periods of use, allowing operators to comfortably perform more tests throughout the day. This enhances productivity and ensures stable, precise handling for accurate measurements in diverse working environments.
This Professional-Grade Gold Tester Gun offers outstanding accuracy, achieving 0.03% accuracy for 9999 gold. This high level of precision is vital for the precious metals industry, enabling accurate valuation, confident purchasing, and robust fraud prevention, ensuring you can distinguish even minute differences in gold purity.
The VRAY VR-H5 Professional-Grade Gold Tester Gun provides rapid results in just 30 seconds. This quick test time allows for high-volume sample throughput, streamlines customer interactions in retail settings, and enables fast decision-making in applications like scrap metal sorting or field geology, maximizing efficiency.
Yes, this Professional-Grade Gold Tester Gun is highly versatile. It's capable of performing non-destructive elemental analysis on solid, liquid, and powder samples. This broad compatibility means you can use it for various applications, from testing gold jewelry and scrap to identifying different metal alloys, and even analyzing some geological samples or industrial liquids.
This Professional-Grade Gold Tester Gun uses an intelligent battery system with MSBUS bus, designed to comply with air dangerous goods transport regulations. A single battery provides approximately 8 hours of continuous work. This ensures extended operation in the field without needing external power sources, making it a truly mobile and reliable tool for professionals.
