Product Details:
| Place of Origin: | XRF Analyzer Manufacturer |
| Brand Name: | VRAY |
| Certification: | ISO CE GOST |
| Model Number: | VR-S7 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | 20000$-22000$ |
| Packaging Details: | Strong Case |
| Delivery Time: | 7 days |
| Payment Terms: | TT |
| Supply Ability: | 500 units per month |
A Multi-Element XRF Mineral Analyzer is a sophisticated X-ray Fluorescence (XRF) instrument specifically designed for rapid, non-destructive, and highly accurate elemental analysis of mineral samples. These analyzers are capable of detecting a wide range of elements simultaneously, from lighter to heavier atomic numbers. When equipped with an SDD High-precision detector, they offer superior spectral resolution and speed, making them indispensable for geological exploration, mining, and metallurgy where precise and comprehensive elemental quantification of various minerals is crucial for informed decision-making.
Model | VR-S7 |
Type | Multi-Element XRF Mineral Analyzer |
Price | 20000$-22000$ |
Machine size | 360 x 510 x 350mm |
Chamber size | 270 x 160 x 120mm |
N/G Weight | 31Kg/40KG |
Test time | 30s |
Test range | Solid/liquid/ powder |
Detector type | High sensitivity SDD detector |
Test accuracy | 0.01% for 9999 gold |
Element range | K(19)~U(92) |
X-ray tube | 50W (50 kV, 1mA) micro-focused beryllium window |
Collimator | ϕ1.5mm |
Screen | 11.6" touchscreen |
Safety protection | Equipped with a dedicated T-shaped radiator to dissipate the heat； no need to wait for cooling of |
Inbuilt Computer | i5-1035G7 window 11 |
Rated power | 100W |
Temperature | 10℃～35℃ |
The VRAY VR-S7 Multi-Element XRF Mineral Analyzer is a cutting-edge, all-in-one desktop gold tester meticulously engineered for highly accurate and comprehensive elemental analysis, featuring a state-of-the-art SDD High-precision detector.
This Multi-Element XRF Mineral Analyzer excels in detecting a broad range of elements from K(19) to U(92), providing detailed insights into mineral compositions. Its High sensitivity SDD detector ensures exceptional precision, achieving a remarkable 0.01% accuracy for 9999 gold. Coupled with a powerful 50W micro-focused beryllium window X-ray tube and a ϕ1.5mm collimator, it delivers ultra-fast 30-second test times for solid, liquid, or powder samples. The integrated i5-1035G7 Windows 11 computer and an 11.6" touchscreen offer a seamless, intuitive user experience. Despite its robust capabilities, it maintains a compact size (360 x 510 x 350mm) and features a dedicated T-shaped radiator for continuous, safe operation. Priced between $20,000-$22,000, the VR-S7 is the definitive choice for high-precision, multi-element mineral analysis.
The VRAY VR-S7 Multi-Element XRF Mineral Analyzer is loaded with features for high-performance mineral analysis:
SDD High-precision Detector: Equipped with a High sensitivity SDD detector for superior energy resolution, enabling highly accurate and precise elemental quantification.
Broad Elemental Range: Detects elements from K(19) to U(92), providing comprehensive insights into mineral composition.
Exceptional Accuracy: Achieves an industry-leading 0.01% accuracy for 9999 gold.
Rapid Test Time: Delivers results in an ultra-fast 30 seconds, ideal for high-volume analysis.
Powerful X-ray Source: Features a 50W micro-focused beryllium window X-ray tube for efficient and stable excitation.
Versatile Sample Testing: Capable of analyzing solid, liquid, and powder samples.
Integrated Computer & Screen: Comes with an inbuilt i5-1035G7 Windows 11 computer and an 11.6" touchscreen for intuitive operation and data management.
Compact Design: Despite its power, it maintains a manageable size (360 x 510 x 350mm) for desktop use.
Safety & Reliability: Equipped with a dedicated T-shaped radiator for continuous operation without cooling delays.
The Multi-Element XRF Mineral Analyzer with an SDD High-precision detector solves several critical problems in mineral analysis:
Slow Lab Turnaround Times: Eliminates the need to send samples to external labs, providing 30-second test times for immediate, on-site results. This drastically speeds up decision-making in mining and exploration.
Limited Elemental Scope: Its ability to analyze a broad range of elements from K(19) to U(92) provides a comprehensive understanding of mineral composition, which is vital for identifying complex ore bodies and impurities.
Inaccurate Valuation: The 0.01% accuracy for 9999 gold and high precision for other elements ensures precise material valuation, preventing financial losses due to misidentified or undervalued minerals.
Destructive Testing Limitations: As a non-destructive method, it preserves valuable samples, which is crucial for rare minerals, historical artifacts, or samples needed for further analysis.
Complex Sample Preparation: Can analyze solid, liquid, or powder samples, reducing the need for extensive and time-consuming sample preparation.
Operational Bottlenecks: Its efficiency and integrated computer with an intuitive touchscreen streamline the analysis process, reducing bottlenecks in high-volume testing environments.
A Multi-Element XRF Mineral Analyzer is an essential tool for professionals and organizations involved in:
Geological Exploration Companies: For rapid identification of mineral deposits, mapping elemental distributions, and preliminary grade assessment in the field or core labs.
Mining Operations: For on-site quality control of ore grade, identifying contaminants, and optimizing processing parameters at various stages of mining.
Mineral Processing Plants: To monitor and control the elemental composition of feed, concentrates, and tailings, ensuring efficient recovery and purity.
Metallurgical Industries: For quality control of raw materials, alloys, and finished metal products, verifying elemental composition and identifying impurities.
Research & Academic Institutions: For non-destructive elemental analysis in geological studies, materials science, and environmental research.
Precious Metal Refineries: While primarily a "mineral analyzer," its 0.01% accuracy for 9999 gold makes it an extremely high-precision tool for verifying gold and other precious metals in mineral concentrates or refined products.
Environmental Monitoring Agencies: For screening soils, water, and industrial waste for heavy metal contamination in environmental assessment.
The Multi-Element XRF Mineral Analyzer (VRAY VR-S7) offers compelling advantages:
Unrivaled Precision: The SDD High-precision detector provides exceptional 0.01% accuracy for 9999 gold and superior elemental resolution across the K(19) to U(92) range, delivering trustworthy results.
Blazing Speed: With 30-second test times, it significantly accelerates analysis workflows, enabling high-volume sample processing and immediate decision-making.
Comprehensive Analysis: Its broad elemental range means you get a complete picture of your mineral samples, detecting both major and trace elements crucial for resource evaluation.
Non-Destructive Testing: Preserves valuable samples, which is vital for irreplaceable geological specimens or finished products.
User-Friendly & Integrated: The inbuilt i5-1035G7 Windows 11 computer and 11.6" touchscreen create a seamless and intuitive user experience, simplifying complex analysis.
Robust & Stable: Designed for continuous operation with efficient heat dissipation, ensuring consistent performance in demanding environments.
The VRAY VR-S7 Multi-Element XRF Mineral Analyzer is priced between $20,000-$22,000. This investment, while significant, offers a strong Return on Investment (ROI) for professional mineral analysis:
ROI Analysis:
Optimized Resource Extraction: Precise grade control and mineral identification can significantly improve mining efficiency and recovery rates, directly impacting profitability.
Fraud and Contamination Prevention: The 0.01% accuracy for 9999 gold and high precision for other elements prevent costly errors from misidentified materials or contaminants in mineral processing.
Reduced Lab Costs & Delays: Performing in-house, rapid analysis eliminates the need for expensive and time-consuming external laboratory services, saving both money and critical project time.
Faster Decision-Making: Instant access to accurate elemental data enables quick adjustments in exploration strategies, processing parameters, and trading decisions.
Enhanced Exploration Success: Accurate initial screening of geological samples can lead to more efficient targeting of viable mineral deposits, reducing overall exploration costs.
Increased Reputation: Consistent, accurate, and rapid analysis builds a strong reputation for reliability in a competitive industry.
The VRAY VR-S7 Multi-Element XRF Mineral Analyzer offers key areas for customization to optimize its performance for specific mineral analysis needs:
Application-Specific Calibration: While the analyzer comes with standard calibrations, custom calibration curves can be developed for unique mineral matrices or specific elemental concentrations relevant to your particular samples (e.g., specific ore types).
Reporting Templates: Custom report templates can be configured to meet specific internal documentation requirements or client deliverables for mineral analysis results.
Software Enhancements: Depending on specific project needs, there may be possibilities for custom software modules or data integration features for specialized mineralogical applications (to be confirmed with manufacturer).
The VRAY VR-S7 is a Multi-Element XRF Mineral Analyzer because it's capable of detecting elements across a broad range, from K(19) to U(92), providing comprehensive elemental profiles of mineral samples. Its SDD High-precision detector is key to its high accuracy, enabling exceptionally precise quantification of various elements, including an outstanding 0.01% accuracy for 9999 gold.
The SDD High-precision detector significantly enhances the performance of this Multi-Element XRF Mineral Analyzer by offering superior energy resolution. This allows for better separation of closely spaced elemental peaks in the XRF spectrum, resulting in more accurate and reliable quantification of elements, particularly for complex mineral matrices or trace element analysis.
This Multi-Element XRF Mineral Analyzer provides results in an ultra-fast 30 seconds. This rapid test time is crucial for mineral analysis, especially in mining and exploration, as it allows for quick turnaround of samples, enabling immediate decision-making on ore sorting, grade control, and drilling strategies, significantly boosting operational efficiency.
This Multi-Element XRF Mineral Analyzer is versatile and capable of performing non-destructive elemental analysis on solid, liquid, and powder samples. This makes it suitable for analyzing a wide range of mineral forms, including rock cores, crushed ore, geological soils, and even solutions encountered in mineral processing or environmental studies.
The Multi-Element XRF Mineral Analyzer utilizes a powerful 50W (50 kV, 1mA) micro-focused beryllium window X-ray tube. The beryllium window is advantageous because it allows for efficient excitation of both light and heavy elements, enhancing the analyzer's capability to detect a wide spectrum of elements from K(19) to U(92), providing robust and reliable X-ray generation.
This Multi-Element XRF Mineral Analyzer features an inbuilt i5-1035G7 Windows 11 computer and an 11.6" touchscreen. This integrated system provides a modern, powerful, and intuitive user interface for seamless operation, data processing, and results display. The large touchscreen enhances user interaction and simplifies complex mineral data interpretation.
