Product Details:
| Place of Origin: | XRF Analyzer Supplier |
| Brand Name: | VRAY |
| Certification: | FCC, CE, ROHS |
| Model Number: | VR-M5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | 15000$-18000$ |
| Packaging Details: | Strong Case |
| Delivery Time: | 7 days |
| Payment Terms: | TT |
| Supply Ability: | 500 units per month |
A Premium Portable XRF Analyzer is a high-performance, mobile X-ray Fluorescence (XRF) instrument that delivers exceptional accuracy, speed, and reliability in a compact, field-ready design. These analyzers stand out due to their superior components, advanced features like retractable color touch screen displays, and robust build quality, ensuring consistent and precise elemental analysis in diverse on-site applications. They are built for professionals who demand laboratory-grade results and efficiency in a truly portable package.
Model | VR-M5 |
Type | Premium Portable XRF Analyzer |
Price | 15000$-18000$ |
Machine size | 206 x 200 x 278 mm |
Chamber size | 500 x 400 x 400mm |
N/G Weight | 4.1Kg/11.1KG |
Test time | 30s |
Test range | Solid/liquid/ powder |
Detector type | Customized Si-Pin detector from USA |
Test accuracy | 0.05% for 9999 gold |
Memory | 32GB |
Sreen | 5.7" retractable color touch screen |
Camera | Built-in 5 million high-definition camera |
Safety protection | Equipped with a dedicated T-shaped radiator to dissipate the heat； no need to wait for cooling of |
Data transmission | USB or bluetooth |
Humidity | 40%-70%（Noncondensing） |
Temperature | -20℃～50℃ |
The VRAY VR-M5 Premium Portable XRF Analyzer is a state-of-the-art instrument designed for demanding on-site analysis, distinguished by its innovative and user-friendly retractable color touch screen display.
This Portable XRF Analyzer features a Customized Si-Pin detector from USA, delivering outstanding 0.05% accuracy for 9999 gold with rapid 30-second test times. It's incredibly versatile, capable of analyzing solid, liquid, or powder samples. The analyzer's compact size (206 x 200 x 278mm) and lightweight design (4.1Kg N/G Weight) ensure effortless portability. Its standout 5.7" retractable color touch screen provides clear visuals and intuitive navigation, complemented by a built-in 5 million high-definition camera for precise sample targeting. With an intelligent battery system providing approximately 8 hours of continuous work and robust operation across a wide temperature range of -20℃ to 50℃, the VR-M5 is the definitive Premium Portable XRF Analyzer for high-precision, mobile elemental analysis.
The VRAY VR-M5 Premium Portable XRF Analyzer is equipped with an impressive array of features:
Retractable Color Touch Screen Display: Features an innovative 5.7" retractable color touch screen for clear visibility, intuitive control, and added screen protection when not in use.
High Accuracy & Speed: Delivers 0.05% accuracy for 9999 gold in just 30 seconds with a Customized Si-Pin detector from USA.
Exceptional Portability: Weighs only 4.1Kg (N/G Weight), making it easy to carry and operate in the field.
Long Battery Endurance: Provides approximately 8 hours of continuous work on a single charge.
Versatile Sample Range: Capable of analyzing solid, liquid, and powder samples.
High-Definition Camera: Includes a built-in 5 million high-definition camera for precise sample targeting and image documentation.
Robust Environmental Tolerance: Operates reliably in temperatures from -20℃ to 50℃ and humidity of 40%-70% (Noncondensing).
Efficient Heat Dissipation: Equipped with a dedicated T-shaped radiator for continuous, stable operation.
The Premium Portable XRF Analyzer is an invaluable tool across various industries requiring precise and mobile elemental analysis:
Precious Metal Buying & Selling: Rapid and accurate verification of gold, silver, platinum, and palladium purity in jewelry, coins, and scrap for immediate transactions in stores or on-site.
Scrap Metal Recycling: On-site identification and sorting of various metal alloys, including stainless steels, aluminum alloys, and copper alloys, to ensure correct valuation and prevent material mix-ups.
Mining & Exploration: Field-based elemental analysis of geological samples (rocks, soils, ores) for mineral exploration, grade control, and geological mapping.
Pawnshops: Quick and reliable authentication and valuation of precious metal items brought in by customers.
Quality Control & PMI (Positive Material Identification): Verification of material composition in manufacturing, construction, and petrochemical industries to ensure alloy conformance and safety.
Art & Archaeology: Non-destructive analysis of artifacts, historical objects, and artworks for elemental composition to determine provenance and aid in conservation efforts.
The VRAY VR-M5 Premium Portable XRF Analyzer offers some key customization options to tailor its performance to specific analytical needs:
Excitation Source Target Material: While Silver (Ag) is standard, optional X-ray tube target materials include Gold (Au), Tungsten (W), and Rhodium (Rh). Choosing a specific target can optimize the analyzer's sensitivity and detection limits for particular elements, enhancing its performance for your unique applications.
Application-Specific Calibration: The software can be calibrated for specific alloy types or matrices not covered by standard calibration curves, ensuring optimal accuracy for niche materials.
The VRAY VR-M5 Premium Portable XRF Analyzer is priced between $15,000-$18,000. This investment offers a significant Return on Investment (ROI) for professionals needing high-performance, mobile analysis:
ROI Analysis:
Fraud Prevention: The 0.05% accuracy for 9999 gold virtually eliminates errors from misidentified or counterfeit materials, quickly saving more than the analyzer's cost.
Increased Efficiency & Throughput: 30-second test times and effortless portability allow for a much higher volume of analyses per day, directly boosting productivity and revenue.
Enhanced Reputation: Providing transparent, accurate, and on-the-spot analysis builds immense trust with customers and partners.
Reduced Operational Costs: Minimizes reliance on costly and time-consuming external lab services, saving both money and logistical efforts.
Versatile Revenue Streams: Its portability allows for mobile services, opening new opportunities for on-site appraisals or material identification that generate additional income.
Using the VRAY VR-M5 Premium Portable XRF Analyzer with its retractable color touch screen display is intuitive and efficient:
Power On: Extend the 5.7" retractable color touch screen display and power on the analyzer. The display will light up, showing the main interface.
Position Sample: Place the analyzer's nose directly onto the sample you wish to test (solid, liquid, or powder). The built-in 5 million high-definition camera provides a live view on the screen to help you precisely target the measurement spot.
Initiate Test: Tap the "Start" or "Analyze" button on the touch screen. The X-ray will activate, and the analysis will begin.
View Results: In just 30 seconds, the elemental composition and purity (e.g., gold karat) will be displayed clearly on the screen. The results can be saved to the 32GB memory or transmitted via USB or Bluetooth.
The VRAY VR-M5 is a Premium Portable XRF Analyzer due to its high accuracy (0.05% for 9999 gold), rapid test times (30s), and robust design. A standout feature is its 5.7" retractable color touch screen display, which offers superior visibility and user interaction while providing added protection for the screen when the analyzer is not in use, making it highly suitable for demanding field environments.
The retractable color touch screen display significantly enhances the user experience by offering an intuitive interface for navigating menus, viewing results clearly, and controlling the analyzer. Its retractable design protects the screen from damage during transport or in rugged outdoor environments, ensuring longevity and reliability for a Portable XRF Analyzer that's often on the move.
This Premium Portable XRF Analyzer offers exceptional accuracy for gold purity, achieving 0.05% for 9999 gold. This high level of precision is critical for professionals dealing with valuable precious metals, ensuring reliable valuations and confident transactions. The accuracy is a direct result of its Customized Si-Pin detector from USA.
The VRAY VR-M5 Premium Portable XRF Analyzer is equipped with an intelligent battery system that provides approximately 8 hours of continuous work on a single charge. This extended battery life is vital for a Portable XRF Analyzer, enabling users to perform extensive testing sessions in the field or at remote locations without concerns about power, maximizing productivity.
Yes, this Premium Portable XRF Analyzer is highly versatile and capable of performing non-destructive elemental analysis on solid, liquid, and powder samples. This broad compatibility makes it an ideal tool for diverse applications in the field, from identifying metal alloys in scrap to analyzing solutions or powdered materials, all with a quick 30-second test time.
This Premium Portable XRF Analyzer is built for resilience, capable of operating reliably in a wide temperature range from -20℃ to 50℃ and in humidity between 40%-70% (Noncondensing). This robust environmental tolerance ensures that the VR-M5 can perform accurately and consistently in diverse outdoor and industrial settings, living up to its promise as a truly portable and reliable analytical tool.
